    When we compile our program, it requires memory to execute. In high-level languages, the operating system and the translator take care of memory management. The memory that would be assigned to a program depends on the operating system and its memory management architecture. This article details stack vs heap. In most programming languages, like C++, C, and Java, the operating system divides the program into four memory blocks that are code, static or global, stack and heap.

    • The code block handles instructions.
    • The static (or global ) block deals with global variables.
    • Stack deals with functions and local variables.
    • The heap block deals with dynamic variables and functions.

    Here in this article, we will only compare the two most important blocks of memory management, which are stack and heap. Before detailing stack vs heap, let's first know the two in brief.

    What is Stack Memory?

    The stack memory is the contiguous block of memory that handles the program functions (including the main() function as well as user-defined functions) and local variables. It stores all the functions and variables temporarily until their execution. It basically works on the concept of stack data structure , which follows the LIFO (Last in First Out) principle . Stack uses push and pop operations to execute the function. The function pushed in the stack memory first executes in the last because of the LIFO principle. The main advantage of stack memory is that the developer does not need to allocate and deallocate memory for the variables and functions. Stack handles all of it for you. Once the function call is done, the stack frees the memory automatically by popping out the functions and their variables from the memory block.

    Advantages and Disadvantages of Stack Memory

    Advantages

    • CPU manages the memory allocation and deallocation.
    • The Object gets deleted automatically once the work is done.
    • It is more memory efficient.
    • Accessing and executing speed is very fast.
    • Stack follows the concept of Last in First Out (LIFO).

    Disadvantages

    • Memory is limited.
    • With many objects and limited memory, the stack can overflow, and it can crash the program.
    • Random access is not possible.

    What is Heap Memory?

    The heap memory is that part of the memory block which is controlled by the user rather than the operating system. It is also known as dynamic memory. A user can manually control the heap memory, and in this memory region, users have control over how much memory they want to allocate to the program functions and variables. In the stack memory, the CPU allocates and deallocates memory to the program functions and variables automatically, but in the heap memory, the user has to take care of the memory allocation and deallocation.

    If the user allocates the heap memory to one of its variables and does not deallocate, it will be stored in the memory forever. This can cause many problems because each block of memory is important, and no one wants any unwanted variable or function to occupy the program memory. In C++ and C, we use malloc(), calloc(), and new to allocate heap memory to a variable. To deallocate the memory, we use the free and delete statements.

    Advantages and Disadvantages of Heap Memory

    Advantages

    • The user has the control over the memory system.
    • Users allocate and deallocate the memory.
    • The object would not be killed until the user wants.
    • The program does not limit the memory size, and it reduces the chances of a program crash.
    • Randomly accessing any variable is possible.

    Disadvantages

    • Access time is very slow.
    • It is more complex to implement.

    Stack vs Heap

    There are several differences between stack and heap memories. We'll discuss each one by one, starting with the type of memory structure.

    1) Type of Data Structure

    Stack is a linear memory structure. This means that data is stored and accessed in a linear sequence. Heap, however, is a hierarchical data structure and thus, doesn't follow a linear sequence for data accessing and storage.

    2) Speed

    Compared to a stack, a heap is slower in access speed.

    3) Memory Management

    In stack, the CPU handles the memory management with the help of the operating system. Memory allocation and deallocation happen automatically. Unlike a stack, the user is in control of memory management in a heap. Thus, the user needs to allocate and deallocate memory.

    4) Variable Scope

    Variable scope is limited in the stack until the function execution. In a heap, the variable will remain in the memory until using the deallocation statement.

    5) Memory Size

    The stack provides a limited memory that depends upon the operating system. Moreover, if the program requires more than the memory available, the program will crash. Unlike stack, though, heap does not have a specific limit on the memory size.

    6) Variable Size

    We cannot resize the variables in a stack, but we can resize the same in a heap.

    7) Flexibility

    The stack is not flexible because it provides a limited amount of memory. Heap, on the contrary, is very flexible as it does not impose any limitation on the memory size.

    Stack vs Heap: A Head-to-Head Comparison

    Stack Heap

    Memory Structure

    Stack is a linear data structure. Heap is a hierarchical data structure.

    Speed

    Stack has high access speed. Heap has slow access speed as compared to the stack.

    Memory Management

    In the stack, the CPU and OS handle memory management. Thus, memory allocation and deallocation are automatic. The user controls the memory management in a heap.

    Variable Scope

    Limited variable scope until the function execution. The variable remains in the memory until deallocation.

    Memory Size

    The stack provides limited memory that depends on the OS. Heap does not have a specific limit on the memory size.

    Variable size

    In a stack, we cannot resize the variables. We can resize the variables in a heap.

    Flexible

    Not flexible. Highly flexible.

    When to Use Heap?

    We use heap memory when we deal with a large number of objects, and we require a large amount of memory to execute our program. We can also use heap when we want the functions and variables to run until the program execution.

    When to Use Stack?

    Stack is usually used when we have a few objects and functions. It is very fast and thus, provides high efficiency to program with fewer objects or functions.

    Conclusion

    Stack vs heap is a common topic among developers. Many times developers are confused about which one to choose. We hope that this article will help you to clear your confusion and choose one that fulfills your requirements.

    People are also reading:

    FAQs


    While the stack is a linear data structure, the heap is a hierarchical data structure. In the stack, the memory is allocated in a contagious block, whereas in the heap, the memory is allocated in random order.

    The stack is of fixed size and does not support resizing the variables. On the other, the heap supports resizing variables and is not of fixed size. So, the heap is more flexible than the stack.

    There are three different ways to implement the stack. They are simple array-based, using dynamic memory, and Linked list based.

    We can implement the heap using arrays and trees.

    Stack is ideal for static memory allocation, while heap is ideal for dynamic memory allocation.

    Yes, the stack is faster than the heap because the former follows the last-in-first out approach, which is pretty simple and faster.
