Selenium is one of the most widely used automated testing frameworks that automate testing for web applications. It consists of four components: Selenium Remote Control (RC), Selenium Grid, Selenium IDE, and Selenium WebDriver. Each has its unique characteristics and satisfies different testing requirements.
Jason Huggings, in 2004, created Selenium to fulfill the need for a tool that would automate web testing. Selenium is a suite of tools, and each tool is developed by a different developer. Here is the list of developers and their corresponding contributions to the Selenium suite:
- Paul Hammant developed Selenium RC or Selenium 1, the first component of Selenium. It is a server that uses the HTTP protocol to accept commands for the browser.
- Patrick Lightbody developed Selenium Grid, which enables multiple Selenium tests to run parallelly across different machines.
- Shinya Kasatani developed Selenium IDE, an integrated development environment for running test scripts.
- Simon Stewart developed Selenium WebDriver, a successor to Selenium RC.
This article focuses on Selenium Webdriver, one of the most significant components of Selenium. We shall make you familiar with the different features of Selenium Webdriver, its architecture, and browser-specific web drivers. So, let us start with an explanation of Selenium WebDriver.
What is Selenium WebDriver?
Selenium WebDriver is a core component of Selenium and was introduced as a part of Selenium 2.0. It is an interface, enabling us to write instructions that can run across modern browsers. Selenium WebDriver accepts commands via a client API or those sent in Selenese and sends them to a browser. Selenese is a test domain-specific language provided by Selenium.
Selenium WebDriver supports all modern browsers, such as Internet Explorer, Microsoft Edge, Safari, Opera, HTMLUnit, Google Chrome, and Mozilla Firefox . It uses a browser-specific driver to send the commands to a browser and fetch results. Unlike Selenium RC, Selenium WebDriver does not require a dedicated server to run tests.
Instead, it directly communicates with the web browser. Therefore, Selenium WebDriver is relatively faster than Selenium RC. Additionally, we can use Selenium Grid with Selenium WebDriver to run tests on remote machines.
Features of Selenium WebDriver
The following features of Selenium WebDriver make it a powerful and great choice for developers to run cross-browser tests:
1. Multi-Browser Compatibility
Selenium WebDriver supports almost all modern browsers, including Chrome, Firefox, Opera, and Safari. With Selenium WebDriver, you can launch any of the supported browsers using a simple command. For instance, you can launch Google Chrome using the following command: WebDriver driver = new ChromeDriver(); It also supports HTMLUnitDriver, and mobile drivers, such as AndroidDriver, and iPhoneDriver.
2. Multiple Language Support
3. Speed and Performance
Selenium WebDriver offers high performance and speed. Unlike its predecessor, Selenium RC, it directly communicates with a browser without requiring an intermediate server, ensuring superior performance and speed.
4. Handles Dynamic Web Elements
Handling dynamic web elements while performing automation testing is considered one of the most challenging tasks. Nonetheless, Selenium WebDriver makes it easier for developers to handle dynamic web elements, such as checkboxes, alters, and dropdowns. It uses three different methods to handle such elements, namely Absolute XPath, Contains(), and Starts-with().
5. Easy to Identify Web Elements
There is a collection of locators provided by WebDriver that is helpful in finding web elements on a web page. The below is the list of some commonly used locators:
- CSS Selector
Selenium WebDriver Architecture
Selenium 2.0, the latest release of Selenium, is integrated with WebDriver API. This API facilitates communication between different languages and browsers. The Selenium WebDriver architecture consists of four major components, namely Selenium client libraries, JSON wire protocol, browser drivers, and browsers. Let us understand each one of them in detail below:
1. Selenium Client Libraries (a.k.a. Selenium Language Bindings)
Selenium client libraries are different types of jar files that contain classes and methods required for creating automation test scripts. For example, if you choose PHP to write test scripts in your browser, you will need the PHP language bindings. You can download all the supported language bindings or client libraries from here .
2. JSON Wire Protocol
3. Browser Drivers
Each browser has its own browser driver. For example, Google Chrome has ChromeDriver, and Firefox has FirefoxDriver. Without disclosing the internal logic of a browser’s functionality, these drivers establish a connection and communicate with their respective browsers. They act as a bridge between the browser and the test code.
Selenium WebDriver supports almost all modern browsers.
Selenium WebDriver vs Selenium RC
Selenium WebDriver is the improved version of Selenium RC. Selenium RC had many limitations, which led to the development of Selenium WebDriver. The following comparison table illustrates how Selenium WebDriver outperforms Selenium RC:
|Parameters||Selenium Remote Control||Selenium WebDriver|
|Architecture||The architecture of Selenium RC is complex since it involves an intermediate server that facilitates communication between Selenium commands and a browser. You need to install the intermediate RC server before running the test scripts.||The architecture of Selenium WebDriver is simple as it does not require any intermediate server.|
|Speed||Selenium RC is slower than Selenium WebDriver because it uses an intermediate server to communicate with a browser.||It is faster than Selenium WebDriver as it communicates directly with the browser.|
|Browser Support||It does not support HtmlUnit .||Selenium WebDriver supports the HtmlUnit browser, which is a headless and fast browser, accelerating the test execution cycles.|
|API||Selenium RC’s API has confusing and redundant commands, making it more complex.||It has a simple API without any unnecessary commands.|
Types of Browser-specific Web Drivers
To run automation test scripts in browsers, we require browser-specific drivers. Let us discuss a few browser -specific web drivers and learn to write commands to launch them in a browser using different programming languages.
HtmlUnitDriver is a headless browser webdriver in Selenium for HtmlUnit. Although similar to other web drivers, it does not have a graphical user interface. Thus, we cannot see the text execution on the screen. Use the below commands to use HtmlUnitDriver:
WebDriver driver = new HtmlUnitDriver();
IWebDriver driver = new RemoteWebDriver(new Uri("http://127.0.0.1:4444/wd/hub"), DesiredCapbilities.HtmlUnit());
my $driver = Selenium::Remote::Driver->new(browser_name=>'htmlunit', remote_server_addr=> 'localhost');
driver = Selenium::WebDriver.for :remote, :url => "http://localhost:4444/wd/hub", :desired_capabilities => :htmlunit
driver = webdriver.Remote("http://localhost:4444/wd/hub", webdriver.DesiredCapabilities.HTMLUNIT.copy())
FirefoxDriver is a browser engine developed by Mozilla and is also known as Selenium GeckoDriver. It links Selenium test scripts with the Firefox browser. We have listed the commands in different programming languages for using the FirefoxDriver:
WebDriver driver = new FirefoxDriver();
IWebDriver driver = new FirefoxDriver();
my $driver = Selenium::Remote::Driver->new;
driver = Selenium::WebDriver.for :firefox
driver = webdriver.Firefox();
InternetExplorerDriver is used to run the Selenium test scripts on the Internet Explorer browser. It supports Internet Explorer 7 and later. The following are the commands in different programming languages to use the InternetExplorerDriver:
WebDriver driver = new InternetExplorerDriver();
IWebDriver driver = new InternetExplorerDriver();
my $driver = Selenium::Remote::Driver->new(browser_name=>'internet explorer');
driver = Selenium::WebDriver.for :ie
driver = webdriver.Ie()
ChromeDriver works with Google Chrome to automate Selenium test scripts. Insert the below commands in your code to use the ChromeDriver:
WebDriver driver = new ChromeDriver();
IWebDriver driver = new ChromeDriver();
my $driver = Selenium::Remote::Driver->(browser_name => 'chrome');
driver = Selenium::WebDriver.for chrome
driver = webdriver.Chrome()
Selenium WebDriver is a popular choice for developers to write automated cross-browser test scripts. The ease of use, simple architecture, flexibility of language choices, compatibility with Android and iOS, and support for all modern browsers make it a powerful tool for developers and testers.
Want to learn and champion Selenium WebDriver from scratch, you can sign up here for the course.
